Design M FabriPulse
Documents
Locate My Sales Rep
Summary

The Design M FabriPulse pulse-jet fabric dust collector meets the needs of industrial dust collection applications that have low air volume and require small, compact filter sizes. It is engineered to give years of efficient service and minimum downtime for continuous operation.

The Design M collector is built with rugged 12-gauge construction and efficient pulse-jet reconditioning. The bag cartridge assembly consists of four or six foot long bags made from fine denier polyester media. This premium quality fabric enables a 99+% collection efficiency, high operating air-to-cloth ratio (up to 8:1), and excellent dust cake release at minimum pressure loss. Normally, less than 1.0 SCFM of clean, dry compressed air will be required for each 1,000 CFM of dust-laden air, with pressure drop ranging from 3" to 6" w.g. The Design M FabriPulse is available with an optional integral fan and/or final filter, as well as bin vent models for bins and silos.

Details
Efficiency %: 99.90
Media/Filter Area (sqft): 300 to 12000
Grain Loading/cf: Up to 5
Hours of Operation: 24/7
Material Characteristics: Dry, Fibrous
Max Temperature: 400° F
Media Type: Spun Bonded Polyester, Olieophobic, Special, Polyester Felt, Polypropylene, Nomex, P84, Ryton, Telfaire, PTFE Membrane
Type of Collector: Bag

     ■ Material Handling
     ■ Grinding
     ■ Spraying

     ■ Material Handling
     ■ Crushing & Grinding

     ■ Material Handling
     ■ Bunker Ventilation
     ■ Bin Ventilation
     ■ Drying


     ■ Material Handling

     ■ Abrasive Cleaning
     ■ Swing-Frame Grinders
     ■ Shakeout
     ■ Sand Handling
     ■ Tumbling Mills
     ■ Non-Ferrous Melting

     ■ Production Grinding

     ■ Coating Pans
     ■ Flour Handling
     ■ Sugar Granulators

     ■ Material Handling
     ■ Crushing and Screening
     ■ Dryers, Kilns
     ■ Coolers

     ■ Mixers
     ■ Talc Dusting
     ■ Grinding and Buffing
     ■ Plastics Finishing

     ■ Scarfing
     ■ Hot Strip Mills
     ■ Coke Screening

     ■ Saws
     ■ Sanding
     ■ Woodshops

     ■ Soldering (Non-Corrosive)
     ■ Powder Paint
     ■ Lead Melting
     ■ Leather Buffing, Sanding
     ■ Paper Dust
     ■ Silo Bin Vent
